BG Lift CWE 315 Crawler crane

View CWE315-SpecSheet-English

Description

The crawler crane CWE 315 from BG Lift allows its user to transport up to 21,417 lbs, while having a working height of 95′ 9″ and a horizontal reach of 86′ 5″.

Its reduced size allows customers to reach places they would not be able to reach with a regular crane, often narrow areas.

Details

Lifting height: 29.2 m / 95' 9"
Maximum hook capacity: 21,417 lbs / 9714 kg
Brand: BG Lift
Model: CWE 315
Minimum Width: 1.62m / 5' 4"
Minimum Height: 2.43 m / 8'
Maximum horizontal reach: 26.35 m / 86' 5"
Minimum Length: 5.26 m / 15' 3"
Maximum rotation angle: keep on going
Total weight: 22,046 lbs / 10,000 kg
Maximum longitudinal leveling: 25°
Maximum lateral leveling: 25°
Maximum speed: 2.2 km/h
